NWSPEC
NW FTIR 500
NW FTIR 500
Regular price
$0.00 USD
Regular price
Sale price
$0.00 USD
Unit price
per
Couldn't load pickup availability
High sensitivity and stability
Intelligent real-time monitoring of instrument status
Multiple communication
Flexible and convenient testing
Powerful software workstation
igh sensitivity and stability Intelligent real-time monitoring of instrument status
Multiple communication Flexible and convenient testing
Powerful software workstation
Innovations
Real-time diagnosis of instrument status
real-time monitoring of instrument working status, performance
and communication status
Multiples detector options
Besides conventional normal temperature pyroelectric detectors, temperature-stabilized pyroelectric detectors
and semiconductor refrigeration MCT detectors can also be selected to meet the needs of different customers.
“Wire + Wireless” multi-communication mode
Adopting Ethernet and WIFI dual-mode communication to adapt the development trend of "Internet + testing"
instruments. Building a basic platform for users to conduct interconnection testing, remote operation and
maintenance, data cloud computing, etc.
Large sample room
With the large sample chamber design, besides the conventional liquid pool, ATR and other commercially
available conventional accessories, it can also be equipped with special accessories such as thermal red
combination, microscope, etc. At the same time, it also reserves space for users to choose new accessories
Brand-new powerful MainFTOS Suite software workstation
Features
High sensitivity optical system
Cube-corner Michelson interferometer combined with patented fixing mirror alignment technology（Utility model ZL 2013 2
0099730.2：fixing mirror alignment assembly），to ensure long term stability, without the need of dynamic alignment which
needs extra complicated electronic circuits. Reflecting mirrors are coated with gold to provide the maximum light throughput
and ensure the detection sensitivity
High stability modular partition design
Compact structure modular design with layout on cast aluminum base and overall balance of mechanical robustness and
partition heat dissipation, offering higher ability of deformation resistance and less sensitive to vibrations and thermal variations,
greatly improves the mechanical stability and long-term working stability of the instrument.
Intelligent multi-sealed moisture-proof design
Multiple sealed interferometers, large-capacity desiccant cartridge with visible window and easy replacement structure, real
time monitoring of temperature and humidity inside the interferometer, getting rid of influences of high temperature, high
humidity and chemical corrosions to the optical system in many ways.
Innovated integration electronic system
High sensitivity pyroelectric detector pre-amplifier technology, dynamic gain amplification technology, high precision 24-bit A/D
conversion technology, real-time control and data processing technology, digital filter, and network communication technology,
ensuring high quality real-time data collection and high-speed transmission.
Good anti-electromagnetic interference capability
The electronic system is designed to meet CE certification and electromagnetic compatibility requirements, minimizing
electromagnetic radiation in design and technology，in line with green instrument designing concept.
High intensity IR source assembly
High intensity, long lifetime IR source module, with the highest energy distributed in fingerprint region, adopts a reflex sphere
design to obtain even and stable IR radiation. External isolated IR source module and large space heat dissipation chamber
design provide higher thermal stability and stable optical interference.
Specifications
