TQ Series
Triple Quadrupole Mass Spectrometry Platform
A high-performance triple quadrupole mass spectrometry platform combining ultra-high pressure liquid chromatography with advanced tandem MS/MS technology. Designed for demanding quantitative analysis in food safety, pharmaceutical, environmental, clinical, and research applications requiring exceptional sensitivity and selectivity. The system delivers femtogram-level detection limits with fast polarity switching and robust ion optics for complex matrix analysis.
TQ55
Best SellerMaximum sensitivity for small molecule quantification. The standard for routine high-throughput analysis across food safety, environmental, clinical, and pharmaceutical applications.
- Mass Range: 5–1,250 m/z
- IDL: ≤2 fg (reserpine, 99% confidence)
- S/N: ≥800,000:1 for 1 pg reserpine
- Polarity Switch: ≤25 ms
- MRM Speed: >500 channels/s
TQ55X
Extended Range60% wider mass coverage for large molecules. Intact protein and peptide characterization without sensitivity compromise. Future-proof for emerging workflows.
- Mass Range: 5–2,000 m/z
- IDL: ≤4 fg (reserpine, 99% confidence)
- S/N: ≥400,000:1 for 1 pg reserpine
- Polarity Switch: ≤25 ms
- MRM Speed: >500 channels/s
Key Features
Dual Ion Sources
Plug-and-play ESI/APCI with 30-second automatic recognition. No vacuum venting required for switching.
Exceptional Sensitivity
IDL ≤2-4 fg (reserpine, 99% confidence); S/N ≥800,000:1 for 1 pg reserpine.
Fast Switching
Positive/negative polarity switch ≤25 ms; MRM dwell time ≤1 ms.
High-Speed Acquisition
>500 MRM/s channel speed; >30,000 amu/sec scan speed.
Robust Vacuum System
400+300 L/S turbo pump; 40 m³/h mechanical pump with auto power-off protection.
UHPLC Performance
1300 bar pressure capability; 50 μL system delay volume.
Model Comparison
| Specification | TQ55 | TQ55X |
|---|---|---|
| Mass Range | 5–1,250 m/z | 5–2,000 m/z |
| IDL (Reserpine) | ≤2 fg | ≤4 fg |
| Best For | Small molecules, routine analysis | Large peptides, intact proteins |
| Applications | 95% of LC-MS/MS workflows | Proteomics, biopharma |
Applications
Food Safety
Pesticide residues, mycotoxins
Environmental
PFAS, POPs, water monitoring
Clinical
TDM, toxicology, biomarkers
Pharmaceutical
Impurity profiling, PK studies
Forensic
Drugs of abuse, toxicology
Proteomics
Peptide quant, protein analysis
