UV Small Optical Gas Cell GC3030UV
UV Small Optical Gas Cell GC3030UV
Couldn't load pickup availability
The optical gas cells produced by NWSPEC has two types: single reflection and multiple reflection, featuring long optical path(such as 12 and 18m etc), stable optics, good anti-contamination, long lifetime and cost effective etc. The products are mainly applied in air pollution detection, environmental gas monitoring, industrial production process monitoring and CEMS etc. Customization can be fulfilled according to the requirements.
| Items | Specifications |
| Wavelength Range | 190–900nm |
| Optical Path Length | 2.8m, 3.6m |
| Fiber Interface | SMA905 |
| External Dimensions | 247mm x 88mm x 52mm |
| Volume | 447ml |
| Pressurization | <0.15Mpa |
| Temperature Resistance | ≤120℃ |
| Cavity Material | Aluminium alloy |
| Window Material | UV fused silica |
| Air Inlet and Outlet | PC6–01 |
