NWS5700 Spectrometer
NWS5700 Spectrometer
Couldn't load pickup availability
Description
The NWS5700 NIR Spectrometer is a high-performance instrument utilizing an M optical design, SMA905 connector, and cooled detector for sensitive and accurate NIR spectral analysis. It features USB and RS232 interfaces and software for automatic configuration and measurements of radiation, transmittance, absorbance, and reflectance.
Application
Spectral analysis and measurement, including applications in petroleum, chemical, agricultural, and food testing, as well as customer-specific customization.
Specification
|
ITEMS |
SPECIFICATION |
|
Fiber Interface |
SMA 905 |
|
Entrance Slit |
25 μm |
|
Wavelength Range |
900-1700 nm |
|
Spectral Resolution |
5 nm @ 25 μm slit @ Hg lamp 1014 nm |
|
Detector |
High-performance cooled detector |
|
Detector Cooling Temperature |
15°C |
|
Cooling Power Supply |
DC 5V/3A |
|
Pixel Count |
512 |
|
Pixel Size |
25 x 25 μm |
|
Detector Condenser |
Yes |
|
Signal-to-Noise Ratio |
200:1 |
|
ADC Resolution |
16 bits |
|
Integration Time |
0.5 ms - 10 s |
|
Power Supply |
DC 5V/3A |
|
Communication Interface |
USB Type-B |
|
Data Output |
Grayscale value varies with wavelength or pixel |
|
Data Averaging |
1-100 times |
|
Dimensions |
160 mm x 115 mm x 42 mm |
|
Weight |
~1 kg |
|
Fixed Screw Holes |
4 x M4 holes on the bottom |
|
Operating Temperature |
-10°C to 40°C |
|
Storage Temperature |
-20°C to 70°C |
